Kathwada, Ahmedabad, Gujarat
- GST NO. : 24DXPPP2077D1ZA
3.20 Lac - 8.65 Lac / Piece
| Business Type | Manufacturer, Supplier |
| Brand Name | Creative Laser |
| Power Consumption | 2 – 3 Unit / Hours |
| Warranty | Full Machine 1 Year, Laser Tube 6 Month |
| Click to view more | |
Preferred Buyer From
| Location | Anywhere in India |
Product Details
Country of Origin
India
Working Voltage
Single Phase AC220V±10%, 50-60Hz (Required Earthing)
Max Cutting Thickness
12 Mm Acrylic,8 Mm MDF
Model
CL1390, CL1410, CL1313, CL1325, CL1610
Laser Type
Co2
Head Type
Single Head or Dual Head
Working Area
1300*900mm / 1400*1000mm / 1300*1300mm / 1300*2500mm / 1600*1000mm
Laser Power
100W/130W/150W
Laser Source
Sealed Glass Co2 Laser Tube (Reci/Yongli/EFR)
Applicable Cutting Material
Wood, Acrylic, MDF, Leather, Cloth, Rubber, Plastic, Fabric, Paper, Plywood
Machine Body
Mild Steel (High Strength Metallic)
X Y Axis System
Belt (Imported) or Gear Box (depend On Model)
Z Axis System
Manual
Guide System
X Axis = Inside, Y = Outside
Co2 Glass Tube
Yongli / Reci / EFR
Working Table
Honey Comb or Knife Strip
Controller
Ruida RD 6445S (EC) (New model)
Cooling Mode
Water Chiller (S & A 5200 CW Series)
Blower (Air Exhaust)
550 Watt
Power Supply
ZYE Power Supply (Display Screen, Yongli)
Air Compressor
135 Watt
Operating System
Windows 7 32 bit/64 bit/windows 10
Interface System
USB Interface
Driving System
Stepper Motor
Add. Feature Accessories
S&A Chiller CW5200 TG, Hailea Air Compressor ACO-009D 135W, Exhaust Fan 550W, Tool Box
Supported File Format
PLT, DXF, BMP, JPG, GIF, PNG
Min Letter Cutting
1 mm (English Font)
Running Environment
45 Degree C; Humidity 5%-95% (without condensed water)
Weight
350-800 Kg (Depend on model)
Cutting Speed
450-600mm/sec
Engraving Speed
800-1000mm/sec
Working Speed
600mm/sec
Travelling Speed
<500mm/sec
Power Adjustment
1 to 100%
Reposition Accuracy
+0.01mm
Engraving Materials
Marble, Stone, Granite, Glass, Plexiglass, Wood, Acrylic, Mdf, Leather, Cloth, Rubber, Plastic, Fabric, Paper, Plywood
Packaging Details
High Strength Wooden Box
Usage: Laser Cutting And Engraving Of Nonmetalic Materials For Automotive Interiors Cutting Engraving : Car Seat Cover, Car Cushion, Car Mat, Car Carpet, Car Rug, Pillowcase, Air Bag, Auto Dustproof Cover, Seat Belt (safety Belt), Etc.
